2004 PARMIGIANI VBH 3100x65/54 plate bending machine 4 roll

Max. plate thickness at bending: 65 mm

Top roll diameter: 600 mm

Rolls length: 3100 mm

Number of rolls: 4

Number of driving rolls: 2

Central lower roll diameter: 570

Side rolls diameter: 460

Main electrical supply:

-Voltage: 400

-Frequency: 50 Hz

-Phases: 3

Total installed power: 88 Kw

Hydraulic unit oil tank capacity: 1000 liters

Machine dimensions:

-Length: 6300 mm

-Height: 3400 mm

-Height with with top support: 6780 mm

-Width: 3320 mm

-Width with two side supports: 7200 mm

Weight of the machine: 65000 kg

seller offer No. resale 160991014
