1985 ERFURT PEE-250 Eccentric Press - Single Column

or
Call +44 20 3287 0537

Specifications

ManufacturerERFURT
ModelPEE-250
Year1985
Stock Number140668141
Quantity1
Table area1000 x 750 mm
Machine weight13,500 kg

Description

Pressure: 250 ton Throat: 400 mm Holes in the table: 160 mm Ram stroke: 36,126 mm Number of strokes: Continuous operation 40-strokes/min Adjustable ram: 110 mm Table area: 1000 x 750 mm Ram area: 630 x 500 mm dimension machine approx.LxWxH: 3,2 x 1,2 x 3,3 m Machine weight: 13,500 kg
