1980 ERFURT PKZZ 250 Double-crank sheet stamping press
or
Call +44 20 3287 0537
Specifications
| Manufacturer | ERFURT |
| Model | PKZZ 250 |
| Year | 1980 |
| Stock Number | 164819236 |
| Maximum force of slide | T 250 |
| Stroke of slide | mm 400 |
| Weight | 66 ton |
| Height above ground | mm 5000 |
Description
Maximum force of slide: T 250
Stroke of slide: mm 400
Stroke rate per min 12
Adjustability of slide: mm 120
Bed area (W x D): mm 2500x1400
Main motor power: kW 32
Max depth of extraction 100mm
pressing force during
the maximum depth of extraction T E4831468 100
Force holding extract unit: T 50
Height above ground: mm 5000
Weight: 66 ton
